Dimensions

140.20mm (L) × 84mm (W) × 90.10mm (H)

Weight

249g

Voltage

5V DC

Stand-by Current

235mA

Starting Current

315mA

Work Current

320mA

Performance

Image Sensor

CMOS, 640×480 pixels (H×V)

Light Source

- Aimer: Blue LED

- Illumination: Red LED

Field of View

39° (Horizontal) × 29° (Vertical)

Tilt Tolerance

- Roll: 360°

- Pitch: ±65°

- Yaw: ±65°

Print Contrast

≤0.2

Interface

USB 2.0/1.1

Resolution

≥3 mil

Environmental

Operating Temperature

-20°C to 60°C

Storage Temperature

-30°C to 70°C

Humidity

5% to 95% RH (non-condensing)

Shock Resistance

1.2m (5 ft) drop test

Ambient Light Immunity

0-100,000 Lux

Decode Ranges

Code39 (5 mil)

0-7 cm

Code39 (13 mil)

0-17 cm

QR Code (20 mil)

0-11 cm

Symbology Support

1D Codes

Codabar, Code 39, Code 32 Pharmaceutical (PARAF), Interleaved 2 of 5,   NEC 2 of 5,

Code 93, Straight 2 of 5 Industrial/IATA, Matrix 2 of 5,

Code 11, Code 128, GS1-128, UPC-A/E, EAN/JAN-8/13,

MSI, GS1 DataBar (Omni/Ltd/Exp), China Post, Korea Post

2D Codes

DOT Code, Codeblock A/F, PDF417/Micro PDF417,

GS1 Composite, QR Code, Data Matrix,

MaxiCode, Aztec, Hanxin

Default Support

Codabar, Code 39, Interleaved 2 of 5, NEC 2 of 5,

Code 93, Code 128, GS1-128, UPC-A/E0,

EAN/JAN-13/8, GS1-DataBar, PDF417, QR, DM, Aztec
