Weight:

437g

Cable Length:

2m

Dimension:

151mm x 142mm x   84mm

Performance

Light Source:

Red LED

Max Decoding Speed:

2m/s

Resolution:

1280*1024

FOV:

65° (tilt), 65°   (pitch), 360° rotation

Electrical

Interface:

USB

Input Voltage:

DC 5V±5%

Startup Current:

380 mA

Standby Current:

190 mA

Operation Current:

240 mA

DOF

Code

Mils

Min Distance

Max Distance

Code 39

5 mils

0 cm

12 cm

13 mils

0 cm

24cm

Environmental

Operation   Temperature:

-20°C ~ +60°C (-4°F   ~ 140°F)

Storage   Temperature:

-30°C ~+ 70°C   (-22°F ~ 158°F)

Humidity:

5% ~ 95%   (Non-condensing)

Light Level:

0 ~ 100,000 LUX

Reliability

High Temp:

70 °C

Low Temp:

-30 °C

Vibration:

8 G r.m.s., from 10   to 500 Hz, 2 hours per axis, 3 axes

Drop:

0.5m drop test
