Resolution

203 DPI

Printing method

Direct Thermal

Max.print speed

Max. 70mm (2.7") / s

Max.print width

72 mm (2.8")

Max.print length

1778 mm (70")

Media

Media type

Continuous, gap, black mark

Media width

25.4 mm ~ 76 mm

Media thickness

0.06 mm ~0.254 mm

Paper roll diameter

50 mm

Performance Features

Processor

32-bit CPU

Memory

8MB Flash Memory/ 8MB SDRAM

Interface

Stardard   version:USB+Bluetooth   Optional:USB+WIFI/NFC

Screen

0.9”OLED

Sensors

Gap sensor,Cover opening   sensor,Black mark sensor

Fonts/Graphics/Symbologies

Internal fonts

8 alpha-numeric bitmap fonts,   Windows fonts are downloadable from software.

1D bar code

Code 39, Code 93, Code   128UCC, Code 128 subsets A, B, C, Codabar, Interleaved 2 of 5,

EAN-8,EAN-13,EAN-128, UPC-A,   UPC-E, EAN and UPC 2(5) digits add-on,MSI, PLESSEY,

POSTNET, China POST

2D bar code

PDF-417, Maxicode,   DataMatrix, QR code

Rotation

0°,90°,180°,270°

Emulaion

TSPL,EPL,ZPL,DPL,CPCL,ESC/POS

Physical Features

Dimension

120×112×60mm (D×W×H)

Weight

400g

Reliability

Print head life

30 km

Software

Operation system

Windows/Android/iOS

SDK

Windows/Android/iOS

Power supply

Input/Output

Input:AC 100-240V,0.5A   50-60Hz    Output：DC 5V/2A

Battery

2500mAh

Environmental Conditions

Operation environment

 -10 ~ 45°C(14~113°F),Humidity:25 ~ 85% no   condensing

Storage environment

 -40 ~ 60°C(-40~140°F),Humidity:10 ~ 90% no   condensing
