Resolution

203 DPI

Printing method

Direct Thermal

Max.print speed

152 mm (6") / s Max.

Max.print width

108 mm (4.25”)

Max.print length

1778 mm

Media

Media type

Continuous, gap, black mark, fan-fold and   punched hole

Media width

26 mm ~ 118 mm

Media thickness

0.06~0.254 mm (2.36~10mil)

Media core diameter

25.4 ~ 76.2 mm (1 "~ 3 ")

Label length

10 mm ~1778 mm

Performance   Features

Processor

32-bit CPU

Memory

8MB Flash Memory, 8MB SDRAM

Interface

Standard version: USB 2.0             Optional:WIFI/Bluetooth

Sensors

Gap   sensor,Cover opening sensor,Black mark sensor,paper exit sensor

Fonts/Graphics/Symbologies

Internal fonts

8 alpha-numeric bitmap fonts, Windows fonts   are downloadable from software.

1D bar   code

Code 39,   Code 93, Code 128UCC, Code 128 subsets A, B, C, Codabar, Interleaved 2 of 5,

EAN-8,EAN-13,EAN-128,   UPC-A, UPC-E, EAN and UPC 2(5) digits add-on,MSI, PLESSEY,

POSTNET,   China POST

2D bar code

PDF-417, Maxicode, DataMatrix, QR code, Aztec

Rotation

0°,90°,180°,270°

Emulaion

TSPL,EPL,ZPL,DPL

Physical   Features

Dimension

185 mm (L) x 85 mm (W) x 85 mm (H)

Weight

548.6g

Power

Input:AC 100-240V       Output:DC 24V, 2.5A

Software

Driver

Windows/ Linux/ Mac

SDK

Windows/ Android/ iOS

Options

Factory Options

Peeler,Cutter ,RTC

Dealer Options

External paper roll holder                                        Paper   roll spindle

Extension board for external paper roll   holder

Environmental   Conditions

Operation environment

 5 ~   40°C(41~104°F),Humidity: 25 ~ 85% no condensing

Storage environment

 -40 ~   60°C(-40~140°F),Humidity: 10 ~ 90% no condensing
